Lung Ventilator OXIVENT-Oxi4 Plus

Ensures the optimal ventilation therapy in transport situations for all patient groups from neonatal to adult

  CHARACTERISTICS

• High performance portable ventilator supporting intensive care features
• Capability to use at hard conditions for ambulances, hospitals, aircrafts and hospital ships
• Display: 7.1 inch, LCD color touch screen
• 4 hours of battery operating time
• Built-in turbine
• Invasive/Noninvasive ventilation and optional high flow oxygen therapy
• Adult, pediatric and optional neonatal kit software

Mode:

• Invasive Modes: PCV+, P-SIMV, PSV+ Apnea Backup, CPAP/PSV, SBT (optional), APRV, Bilevel, PRVC, PRVC-SIMV, (S)CMV, V-A/C, V-SIMV
• Noninvasive: P-A/C, PSV-S/T, nCPAP, HiFlowO2 (optional)
• Manual

Specification:

• Tidal volume: 30 to 2500 ml (1 to 2500 ml with optional neonatal kit)
• Respiratory frequency: 1 to 120 b/min (optional neonatal 1 to 150 b/min)
• PEEP: 0 to 25 cmH2O
• Oxygen: 21% to 100%
• I:E ratio: 1:10 to 4:1
• Inspiratory time (TI) (Adjustable): 0.10 to 12 s
• Flow trigger:  Closed, 0.5 to 20 l/min
• Pressure trigger: -0.5 to -20 CmH2O
• Inspiratory Flow (Adult / pediatric): Adult – Pediatric: 0-200 l/min  Neonatal: 0 – 40 l/min.

Manufacturer: Modül Grup Mühendislik Ltd, Tyrkey
